770849-7
Manufacturer:
TE Connectivity
Mfr.Part #:
770849-7
Datasheet:
Description:
Headers and Wire Housings Cable, Free Hanging Receptacle, Socket Number of Positions:7 Pitch:3.96 mm
| Parameter | Value |
|---|---|
| Length | 27.686 mm |
| Termination | Crimp |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Height | 6.35 mm |
| Packaging | Bulk |
| Depth | 16.76 mm |
| RoHS | Compliant |
| REACH SVHC | Unknown |
| Pitch | 3.96 mm |
| Current Rating | 6.5 A |
| Flammability Rating | UL94 V-0 |
| Approvals | CSA |
| Orientation | Straight |
| Operating Supply Voltage | 250 V |
| Lifecycle Status | Production (Last Updated: 2 weeks ago) |
| Color | Natural |
| Gender | Receptacle |
| Number of Contacts | 7 |
| Connector Type | Receptacle, Socket |
| Wire/Cable Gauge | 24 AWG |
| Number of Positions | 7 |
| Number of Rows | 1 |
| Housing Material | Nylon |
| Fastening Type | Ramp |
| Connector System | Wire-to-Board |
| Max Voltage Rating (AC) | 205 V |
| Contact Current Rating | 6.5 A |
| Wire Gauge (Max) | 24 AWG |
| Wire Gauge (Min) | 18 AWG |
| Housing Color | Natural, White |
| shrouded | No |
| Mating Post Length | |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 2 weeks ago) |
| Sealable | No |
| Mating Retention | With |
| Termination Post Length |
Stock: 1134
Distributors
pcbx
pcbxUnit Price$0.12970
Ext.Price$0.12970
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.12970 | $0.12970 |
| 10 | $0.12229 | $1.22290 |
| 50 | $0.11530 | $5.76500 |
| 100 | $0.10378 | $10.37800 |
| 500 | $0.09341 | $46.70500 |
| 1000 | $0.09184 | $91.84000 |
| 3000 | $0.09030 | $270.90000 |
| 5000 | $0.08879 | $443.95000 |
